MVVS 3.5/960 Brushless Motor

Total: 0.00

AXi 2820/12 eqivalent 500 size inrunner/outrunner brushless motor with 5mm shaft and high levels of durability as the hardened 5mm shaft running in precision ball races is supported directly in the ends of the motor case. These motors are unbelievably smooth running as a result of the dynamic balancing. We are particularly excited about the fact that MVVS motors require no specialist techniques for servicing and all spares are readily available. MVVS electric motors are produced along with their model engine range at Brno in the Czech Republic.

Technical Data:

RPM/Volt 960
Case diameter 35mm (plus screw flange)
Case length 465mm
Nominal voltage 10v
Shaft’s diameter 5mm
Number of poles 12
Working voltage 8-15V
Recommended current loading 20-30A
Max. load capability 35A/30s
Number of NiCd/Lixx cells 7-12/3-4
Weight 168g

Test Figures:

MVVS 35/960 with 8 cell Hi-Flow 3000 NiMh (3 Series A123 equivalent)
9x6 APC-E 22A 9200 rpm
10x5 APC-E 23A 9000 rpm
10x 7 APC-E 27A 8100 rpm
11x7 APC-E 30.5A 7500 rpm
12x8 APC-E 36.5A 6600 rpm

MVVS 35/960 with 10 cell GP2200 NiMh
(3 Series LiPo equivalent)
10x 7 APC-E 21.2A 8200 rpm
11x7 APC-E 24.5A 7600 rpm
12x8 APC-E 29.7A 6800 rpm
13x8 APC-E 33.5A 6200 rpm

Customer figures with 3S 4000 LiPo (unknown brand)
11x7 APC-E 24.5A 7585 rpm
12x8 APC-E 29.7A 7050 rpm
13x8 APC-E 33.2A 6400 rpm
Expect higher current draw and higher speed with 3S SharkPOWER 3700

MVVS 35/960 with 4S LiPo 3700
(unknown brand)
11x7 APC-E 32.2A 8650 rpm
12x8 APC-E 39.4A 8040 rpm

Test figures are approximate and not taken with calibrated instruments. Figures will vary with controller settings batteries used and state of battery charge.

We recommend Jeti controllers on hard timing for the best results with MVVS electric motors.
